SPECS AND FEATURES
| Model | Weight | Dimensions (L × W × H) | Galley Prep |
|---|---|---|---|
| Kong 4×8 | 1180 lbs | 12 ft × 46.5" × 76" | 15" |
| Kong 5×8 | 1380 lbs | 12 ft × 58.5" × 76" | 15" |
| Kong 6×8 | 1590 lbs | 12 ft × 70.5" × 76" | 15" |
| Kong 5×10 | 1548 lbs | 14 ft × 58.5" × 76" | 15" |
| Trailer Features |
• 31" MT Tires with black rims • Safety cables • Double-wheel front jack • 7-Pin wire harness • Rear hitch for bike rack • 2" receiver (Lock-N-Roll or Max Coupler compatible – bring your own) • Frame coated with primer + bed liner • Flush-mount LED tail lights • Jeep-style 36" square fenders • Axle options: Rugged Hitch Axle-Less Suspension or Timbren Axle-Less Suspension |
||
| Inside Cabin |
• Hardwood floors • Front & rear storage cubbies • Round power outlet + USB ports • Two half-moon air vents • Battery-powered interior LED lighting |
||
| Rear Galley |
• Spice cubby • Battery-operated LED light • Large prep shelf • Removable electrical panel |
||
| Exterior Features |
• 2 solid doors (26”×32”) with deadbolt locks • 2 locking windows with vents • Two exterior half-moon air vents • 2 LED solar lights • Polycore ACM aluminum exterior walls • Solid rear galley door (40”×44”) • Aluminum sungaze trim & black roof molding • NOCO GCP2 shore power plug (20-amp inlet) • Custom steel roof racks (2” square tubes) |
||
| Color Options |
✅ Free: White, Black 🎨 Upgrade ($550): Red, Green, Yellow, Blue, Gun Metal Grey |
||
| Construction Details |
• No wood in structural construction (unless requested) • Komotech Marine Composite panels • Optional Aqua-Ply wood shelves/cubbies • 3mm Polycore Cladding – oil-can free polypropylene • Marine/automotive-grade sealants only (Tiger Seal, SEM, 3M 5200) • Stainless steel hardware throughout • HDPE used in key construction points • Sandwich construction with insulated roof & floor • No silicone or RV-grade sealants used |
||
